× Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m
Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m
Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m
Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m
Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m

Masterlan fiber optic patch cord, LCupc-SCapc, Singlemode 9/125, simplex, 1m

The Masterlan optical patch cord is suitable for connecting active and passive network elements (optical boxes, optical patch panels) or directly connecting of two active devices as switches or routers. Singlemode 9/125um fibers are made from G.657.A2 type and cable is terminated with one LC connector on the first side and one SC connector on the second side. The total cable diameter is 2mm.

Ferrule of LC connector is made as UPC and ferrule of SC connector is made as APC. Cable cover/sleeve is LSZH (Low Smoke Zero Halogen).

The length of the cable is 1m.

Other variants: 2m 3m

Product specification

Part No. LCupc/SCapc-SSM.9/125-01 Number of fibers 1 Fiber type Single Mode Core diameter [µm] 9/125 Optical Connectors SC - LC Optical Connectors LC - SC Purpose Indoor Length [m] 1 Polishing type UPC / APC LSZH (LSOH) Yes
